JT-R380BSW
Joyfirst
Light Source | |
Bulb Specification | Philips MSD Silver 380W/2 LL |
Color temperature | 7800K |
Rated life | 4000 hours |
color | |
3color wheels 12colors+ OpenWhite (Including | CTO 3500K & UV) |
Full CMY Color Mixing | |
GOBOs | |
GOBO Wheel 1 | 10Fixed + Open (1 Beam Reducers Beam Mode) |
GOBO Wheel 2 | 7Rotating/Replaceable + Open (Size |
Modular design for easy servicing and GOBO replacement | |
Effects | |
Prism | 1 8 prism,1 16 prism can be quickly cut in, cut out. It can be rotated in two directions with variable speed Two prisms can be stacked |
Atomization | 1 single-sided high-transmission atomized lens |
focusing | DMX linear focus |
Strobe | Independent dual-chip. 0-15 times/second ultra-high-speed strobe. 0-100% linear dimming |
Dimming | Linear Dimming |
Zoom Range | 2 ~ 45-degrees |
Control | |
Rotation angle | 540° in the horizontal direction, 270° in the vertical direction, with automatic return function |
Control Channels | 21, 24 or 26 |
DMX Modes | 2, RDM (Remote Device Management) |
Control | 3-pin |
Full color display menu | |
Pan/Tilt Speed | Fast to Slow |
Electrical | |
Input voltage | 110V~240V AC, 50/60Hz(Auto Sensing) |
Daisy chain max | 3 fixtures (@120V); 5 fixtures (@230V) |
Power Draw | 500W (4.71A @ 120V; 2.26A @ 220V) |
cooling system | |
Equipped with 9 cooling fans. After the bubble is eliminated for one minute, the fan will enter the silent cooling mode | |
Other functions | |
Display lamp, bulb usage time. Remote control bulb switch function,Fault detection reminder, manual lock screen. | |
Shell and protection grade | |
Aluminum, high temperature/UV resistant engineering plastic, protection grade IP20 | |
Dimensions/Weight | |
Dimensions (LxWxH) | 14.8” x 11.6” x 23.5” / 382 x 299 x 603mm |
Weight | 45 lbs. / 20.5 kg. |
